Krytox 226 FG
Home / Krytox™ & Other Lubricants / Krytox™ Lubricants / Krytox™ Corrugator Grease

Krytox™ 226 FG Corrugator Grease

  • Krytox 227 FG

Krytox™ 226 FG Corrugator grease has an Oil Viscosity of 240 cSt at 40°C and the estimated useful temperature range is -36°C to 260°C.

Krytox Authorized Distributor

CLICK FOR A FORMAL QUOTE OR TO INQUIRE
This product is already in your quote request list.
Browse the list
Category: Krytox™ Corrugator Grease Tags: 226 FG, h1, Krytox
CLICK HERE TO CHAT WITH AN EXPERT ABOUT THIS PRODUCT
  • Krytox 227 FG
Product Categories
  • Conformal Coatings (13)
  • Epoxy Resin Systems (69)
  • Industrial & Medical Coatings (10)
  • Krytox™ & Other Lubricants (133)
    • Krytox™ Lubricants (110)
      • Krytox™ 157 FS Oils (2)
      • Krytox™ Aerospace GREASES & OILS (23)
      • Krytox™ AGL Grease (1)
      • Krytox™ AUT Grease (4)
      • Krytox™ Corrugator Grease (2)
      • Krytox™ EG Greases (2)
      • Krytox™ Fluoro-guard™ Oil (2)
      • Krytox™ Gearbox/ Soot-blower Grease (4)
      • Krytox™ GPL Greases & Oils (35)
      • Krytox™ LVP/ VPF Greases & Oils (4)
      • Krytox™ NRT Grease (4)
      • Krytox™ TM7 Grease (1)
      • Krytox™ TS4 Thread Sealant Grease (1)
      • Krytox™ XHT Greases & Oils (9)
      • Krytox™ XP Greases & Oils (16)
    • Krytox™ Special Packaging (1)
    • PTFE Dry Film Lubricants (5)
    • Teflon™ Lubricants (6)
    • TriboSys Lubricants (12)
  • Mold Release Agents (59)
  • MS Medical (5)
  • Specialty Products (8)
  • Specialty Solvents (36)
  • Uncategorized (2)
  • Description
  • Technical Data
  • Specifications Met

Krytox 226 FG Grease | Setting the standard for the Corrugating Industry

NSF H-1 Food grade certified for incidental food contact

Since the 1980s, Krytox 226 FG anticorrosion grease has set the standard for high temperature bearing lubrication in corrugator applications. These products are the same high-performance formulation the corrugated industry has trusted for years and, we are pleased to announce, are now certified for incidental food contact. Corrugator Krytox 226 FG and Corrugator Krytox 227 FG provide you with peace of mind and full confidence that Krytox™ greases are non-toxic, and completely biologically and environmentally inert. Krytox™ corrugator greases are recommended for use in high-temperature corrugated equipment applications and manufacture of food packaging materials where an H-1 rated lubricant is required. High temperature, extreme pressure Krytox greases excel in the most demanding environments.

Krytox 226 FG | Chemical and Environmental Compatibility

Krytox’s nonoxidizing chemistry and wide temperature range allow them to be used in temperature extremes. Its superior oil film strength reduces friction and abrasive wear to significantly extend equipment life in severe-duty applications. Krytox provides excellent water washout resistance, and superior rust and corrosion protection for bearings and components. Krytox is silicone-free, contains no VOC materials or chlorine, and is not hazardous to the atmosphere or ozone layer.

Krytox lubricants are inert and will not react with any materials they may come in contact with. The polymeric nature of these products is extremely resistant to moisture, so it stays in place during cleaning. Cleaners and disinfectants, both acidic and caustic types, do not affect them. Steam and high temperatures will not damage them. They do not damage plastic or elastomer seals, or cause corrosion to metals. They are nonflammable and are safe for use in oxygen service. For applications that require no additives, we recommend Krytox™ GPL 10X Oil, or  Krytox™ GPL 20X Grease

Miller-Stephenson: Lubrication Experts, Superior Chemistry, Fast Delivery – a potent combination

At Miller-Stephenson, we understand the challenges engineers and scientists face with trying to select the best lubricant for current or new applications.  With over 60 years of real-world experience, our highly trained team of technical experts and field engineers can assist you with identifying and selecting the optimal lubricant that best fits your operational parameter. Our large inventory of high-performance PFPE-base Krytox™ lubricants from Chemours, ensures we have the right lubricant for your needs, regardless of temperature, environment, safety, or performance of your system demands. For further information please review the articles below or contact a Miller-Stephenson representative.

Krytox™ is a trademark of The Chemours Company FC, LLC.

For more benefits and related articles:

To learn more about Krytox NSF H-1 Rated Food Grade Lubricants click here.

To learn more about Krytox Automotive Solutions click here.

To learn more about Krytox Automotive Noise, Harshness and Vibration solutions click here.

For the Krytox Frequently asked questions (FAQ) click here.

For a general Krytox application overview, click here.

With help regarding which Krytox grease is right for you, click here.

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

Property Corrugator Krytox 226 FG Corrugator Krytox 227 FG
NLGI Grade 2 2
ISO Grade of Base Oil 220 460
Specific Gravity 1.95 1.95
Oil Separation, %, 30 hr at 99 °C (210 °F) 3 3
Anticorrosion Additive Sodium Nitrite Sodium Nitrite
Coefficient of Friction, ASTM D2266 0.11 0.11
Thickener PTFE PTFE
Appearance White, creamy consistency White, creamy consistency
Base Oil Viscosity, cSt
at 40 °C (104 °F)
at 100 °C (212 °F)
240
25
440
42
Viscosity Index 134 155
Operating Range, °C (°F) –36–260
(–33–500)
–30–288
(–22–550)
Rust Prevention, ASTM D1743 Pass Pass
Four Ball Wear Scar, ASTM D2266
at 1 hr, 1200 rpm, 107 °C (225 °F), 20 kg
0.4 mm 0.4 mm
Oil Volatility, %, 22 hr at 204 °C (400 °F)
ASTM D2595
3 max. 1 max.

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

  • NSF H-1 Rated
  • ASTM D2266
  • ASTM D1743
  • ASTM D2266
  • ASTM D2595

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.
